-20℃ - -40℃ Low Temperature Freezer
-20℃ - -40℃ Low Temperature Freezer
Cooling System
● Temperature Range: :-20℃ - -40℃ .
● Microprocessing controller, LED display, temperature adjustment and display accuracy is 0.1℃ .
● The outer door adopts unique sealing structure, which can ensure the freezer with good sealing and heat preservation performance.
● The upper and lower storage spaces with two completely independent cooling system, temperature control and display.
● Compressors are efficient and reliable.
Safety
● Build-in back-up battery to display temperature and alarm information for up to 8 hours, if AC power is failure.
● With high/low temperature alarm, sensor failure alarm, power failure alarm, door ajar alarm. Two ways of alarm: visual and audible.
● The handle has a padlock hole that can be used to provide an extra protection of security for storage.
● Button on the control panel can be locked to avoid setting parameters being changed due to misoperation.
● With compressor delay start protection function when power off restart.
● Efficient and environmentally friendly HC refrigerant is used.
● Build-in mechanical lock to ensure the safety of storage.
● Safe mode will be ran automatically in case of sensor failure to ensure the temperature for storage.
Easy Operation
● Door frame can be heated to avoid condensation.
● Standard testing ports for easy access to external test tools.
● Buzzing alarm can also be set to mute if required.
● Standard drawer, easy to storage and management.
● The bottom is provided with leveling feet to ensure the levelness of the freezer body during installation.
● In case of failure, the control screen displays real-time temperature and corresponding alarm code, which is convenient for trouble shooting.
● The specially designed handle can balance the pressure difference between inside and outside the chamber while pulling, to ensure outer door can be opened easily and smoothly.
Technical Specifications
| Model | BDW-40L530D |
| Temperature Range 〔℃〕 | -20 - -40 |
| Effective Capacity 〔Liters〕 | 265 × 2 |
| Insulation Thickness 〔mm〕 | 95 |
| Exterior dimensions W x D x H〔mm〕 | 900 x 820 x 1828 |
| Up chamber Interior dimensions W1 x D1 x H1〔mm〕 | 651 x 630 x 635 |
| Down chamber Interior dimensions W1 x D1 x H1〔mm〕 | 651 x 630 x 635 |
| Door opening W2 x H2〔mm〕 | 1431 x 1501 |
| Exterior Finishing | White Plastic Coated Galvanised Steel |
| Interior Finishing | |
| Levels | 3×2 |
| Drawers | 3×3×2 |
| Mechanical Lock | Yes |
| Battery | Yes |
| Temperature Sensor in Chamber | Yes |
| Gasket Heating | Yes |
| Controller Type | Digital Screen |
| Refrigerant | HC |
| Voltage/Frequency〔V/Hz〕 | AC220/50 |
| Rated Power〔W〕 | 340 |
| Net Weight〔kg〕 | 160 |
| Power Failure Alarm | Yes |
| Temperature Sensor Failure Alarm | Yes |
| High/Low Temperature Alarm | Yes |
| Door Ajar Alarm | Yes |
| Temperature Resolution〔℃〕 | 0.1 |
| Temperature Uniformity〔℃〕 | ≤6 |
| Pull Down Time〔h〕 | ≤4.1 |
