Bluepard Line
Oven/Incubator
Oven/Incubator (dual-purpose)
Features
● Polished stainless-steel chamber, semicircular arcs at corners for easy cleaning, and the spacebetween the shelves in the chamber is adjustable.
● Microprocessor temperature controller ensures a precise and reliable control.
● Forced-air convection.
● Double Layer glass door, larger viewing window.
● Independent temperature-limiting Alarm.
Options
● Independent temperature-limiting Alarm system.
● RS485 connector.
● Intelligent programmable temperature controller.
Specifications
| Model | PH-010 (A) | PH-030 (A) | PH-050 (A) | PH-070 (A) | PH-140 (A) | PH-240 (A) |
| Electrical Requirement | 220V 50HZ | |||||
| Temperature Range | a. as incubator:RT+5~80℃ b.as Oven:80~220℃ | |||||
| Display Resolution | 0.1℃ | |||||
| Temperature Accuracy | a. ±0.5℃ b. ±1℃ | |||||
| Ambient Temperature | +5~35℃ | |||||
| Power Consumption | 850W | 850W | 1100W | 1550W | 2050W | 2450W |
| Interior Dimension (W×D×H) mm | 250×260×250 | 340×325×320 | 420×395×350 | 450×400×450 | 550×450×550 | 600×500×750 |
| Exterior Dimension (W×D×H )mm | 530×480×420 | 620×490×490 | 720×590×520 | 740×590×630 | 840×570×730 | 880×630×930 |
| Shelves | 2(pcs) | |||||
| Timing Range | 0~5999min | |||||
