CO2 Incubator
With Imported Infrared CO2 Sensor
Features
● Faster CO2 concentration Restoration Speed.
● Imported Infrared sensor can keep CO2 concentration stability and uniformity when door open frequently.
● Polished stainless-steel chamber, semicircular arcs at corners for easy cleaning, and the space between the shelves in the chamber is adjustable.
● Microorganism filter at inlet provides 99.99% filtration of bacteria and dust (Ф<0.3μm) and supplies pure CO2 into the incubator.
● Door temperature controller prevents dewfall on glass door of incubator effectively.
● Independent audible and visible temperature-limiting alarm system ensures experiments run safely.
● Alarm function for temperature difference, CO2 over concentration and concentration difference,door open time, UV working status.
● Auto-controller of fan speed to prevent damage to the samples.
● PID controller with LCD screen ensures precise and reliable control.
● Two-layer stacking available.
● UV light system for periodic sterilization of chamber.
Options
● RS485 Connector: Easy to download and save all the data via RS485 into computer, and identify problems in time.
● High effective filter provides filtration of bacteria and dust.
● CO2 pressure releasing valve.
● Humidity display system.
Model | BPN-40CRH | BPN-80CRH | BPN-150CRH | BPN-190CRH | BPN-240CRH | BPN-500CRH |
Chamber Volume | 40L | 80L | 155L | 190L | 240L | 500L |
Temperature Range | RT+5℃ ~55℃ | |||||
Electrical Requirement | 220V 50Hz | |||||
Power Consumption | 350W | 500W | 750W | 750W | 950W | 1450W |
Ambient Temperature | +5~30℃ | |||||
Heating Method | Air-jacketed, PID Control | |||||
Temperature Resolution | 0.1 | |||||
Temperature Stability | ±0.1℃ | |||||
Temperature uniformity(37℃) | ±0.3℃ | |||||
CO2 Range | 0~ 20% V/V | |||||
CO2 Control Resolution | ±0.1%(IR sensor) | |||||
CO2 Recovery | (Door open 30s,recovery to 5%) ≤ 3min | |||||
Temperature Recovery | (Door open 30s,recovery to 37℃ ) ≤ 8min | |||||
Humidity Method | Natural vaporization ≥ 90% | |||||
Shelves | 2(pcs) | 3(pcs) | 3(pcs) | 3(pcs) | 3(pcs) | |
Interior Dimension (W×H×D)mm | 400×286×350 | 400×450×500 | 480×530×610 | 520×530×690 | 600×630×670 | 700×650×1100 |
Exterior Dimension(W×H×D)mm | 590×440×576 | 590×687×790 | 670×767×880 | 708×710×1030 | 788×837×940 | 880×860×1500 |
Sterilization method | 18hrs (90°C moist heat disinfection) |
