BD Series Overhead stirrer
BD Series Overhead stirrer
The BD Series Overhead stirrer adopts a CNC stepless speed regulator, which is high-speed and convenient, and can digitally display the operating speed, making the machine safer and more reliable. It has advanced technology, low-noise mechanical reduction structure, small size, and large output torque. It is suitable for scientific research, colleges and universities, chemical industry, pharmaceuticals, medical units and other purposes.
Model | BD50 | BD100 | BD150 |
Capacity | 20L | 40L | 60L |
Speed range | 30~2200rpm | ||
Speed display | LCD | ||
Resolution | ±1rpm | ||
Torque | 60N.cm | ||
Max viscosity | 10000mPas | 50000mPas | 80000mPas |
Diamter | 0.5-10mm | ||
Exterior Dimension | 160x80x180 | ||
Net weight | 2.6kg | 2.8kg | 3.0kg |
Protect class | IP42 | ||
RS232 | Yes | ||
Voltage | AC220V50HZ/110V60HZ | ||
Power | 60W | 120W | 160W |
