Bluepard Line
TWO&THREE Chambers Vacuum Oven
LCD controller (with timing function)
Features
● Microprocessor controller.
● Dual layer tempered glass door for clear observation.
● Minimum heating time 50% less than traditional vacuum oven.
● Interior chamber made from 304 stainless steel with a mirror polished finish making for easy cleaning.
● Standard with vacuum pump.
● Independent audible and visible temperature-limiting alarm system ensures experiments run safely (Option).
● Each chamber can be heated, vacuumed, and injected with nitrogen independently without interfering with each other.
Options
● LED lamp
● Oil mist filter
● Inert gas valve
| Model | BPZ-6090-2 (2 chambers） | BPZ-6120-2 (2 chambers) | BPZ-6210-2 (2 chambers) | BPZ-6140-3 (3 chambers) |
| Electrical Requirement | AC220V 50HZ | |||
| Controller | Controller | |||
| Power Consumption | 2200W | 3350W | 3550W | 3100W |
| Temperature Range | RT+10 ～ 200℃ | |||
| Display Resolution | 0.1 | |||
| Temperature Stability | ±1℃ | |||
| Vacuum Degree1 | 133Pa | |||
| Ambient Temperature | +5~40℃ | |||
| Chamber Volume | 90L×2 | 125L×2 | 216L×2 | 140L×3 |
Interior Dimension (W×D×H) mm | 450×450×450/Chamber | 500×500×500/Chamber | 600×600×600/Chamber | 380×600×620/Chamber |
Exterior Dimension (W×D×H) mm | 740×810×1470 | 790×860×1570 | 880×960×1770 | 880×980×1910 |
| Shelves | 2pcs /Chamber (Independent temp. control） | 3pcs /Chamber (Independent temp. control) | 3pcs /Chamber (Independent temp. control） | 2pcs /Chamber (Independent temp. control) |
| Independent temp. Controller | 2 PCS | 2 PCS | 2 PCS | 3 PCS |
| Chamber Material | 304 Stainless steel | |||
-
