Cooling Incubator

Cooling Incubator

Cooling Incubator (BC/BJ series)

Humanized design:

With casters, flexible and convenient to move.

With reservation and timing functions, there is no need to wait, which effectively improves the efficiency of the experiment.

Available in Chinese and English menus to meet different language needs, with °C / °F conversion.

Safty:

Protection on instruments: Comply international standard secondary temp limiting alarm system. When the heating is out of control or exceeds the maximum limit temperature, the heating is automatically cut off with sound and light alarm, ensure operating is safe without any accident.

Protection on key components: Key components are equipped with over-current, over-temperature, overload and other safety protection to prevent accident.

Protection on samples: When the temperature inside the box is higher or lower than the set temperature, the alarm will start to cut off the heater, with sound and light alarm to remind the operator to protect the sample from normal test without accident.

Protection on operator: The cabinet and door are specially insulated to make the surface temperature of the cabinet low, ensuring the operator's safety and no accidents.

Breakdown message provided: When the instrument breakdown, the message will shown on the screen to help operator clearly check.

Convenient data processing:

The touch screen type standard with a USB interface, which can record the change status of the temperature parameters. The LCD screen is option for USB interface.

It can be equipped with RS232 data interface, which can realize remote control of the machine through software (option).

RS-232 and USB can be selected one of them.

Specifications

Technical parameters

Touch ScreenBC-60BJ-60BC-120BJ-120BC-250BJ-250BC-500BJ-500BC-800BJ-800
LCD controllerBC-60LBJ-60LBC-120LBJ-120LBC-250LBJ-250LBC-500LBJ-500LBC-800LBJ-800L
Capacity(L)68L120L252L495L752L
Temp Range-10 - 80℃
Display Resolution0.1℃
Uniformity±1.0℃
Timing Range1-5999mins
Max number of shelves2(10)3(14)3(16)4(16)4(20)
Max load per shelf20Kg
NW85Kg100Kg120Kg220Kg250Kg

Interior Dimension

W×D×H(mm)

400×380×450500×400×600550×600×750670×725×1020700×860×1250

Exterior Dimension

W×D×H(mm)

545×670×1000645×690×1150695×890×1300850×1095×1935950×1225×2000
Electrical RequirementAC220V/50Hz
Power Consumption1300W1500W1700W2250W2800W
UV lampoptionstandardoptionstandardoptionstandardoptionstandardoptionstandard

BC series Cooling incubator

BJ series Cooling incubator with UV lamp
